Thermal Stability 260C 15 Percent Para Aramid Woven Fabric with Anti Cut Level 3 Heat Resistant Kevlar Fabric

Para-aramid woven fabric weighing 260 gsm is regarded as the benchmark in the realm of high-performance industrial textiles. Manufactured entirely from 100% para-aramid fibers, equivalent to Kevlar® grade, this fabric uniquely integrates natural flame resistance, exceptional tensile strength, and outstanding abrasion durability into a lightweight material.

Unlike flame-retardant fabrics that rely on chemical treatments and gradually lose their protective qualities after several washes, the fire resistance of para-aramid fibers is an intrinsic characteristic at the molecular level. This resistance is embedded within the polymer chain, enabling the fabric to char when exposed to extreme heat without melting, dripping, or fueling combustion. Such properties guarantee consistent and reliable protection throughout the entire lifespan of the product.

The 260 g/m² fabric weight category offers the perfect equilibrium—it is substantial enough to meet rigorous protective requirements while remaining sufficiently lightweight and flexible for comfortable wearable apparel and adaptable composite materials. Furthermore, the plain or twill weave structure provides balanced strength across both warp and weft directions, effectively reducing the directional weaknesses commonly found in unidirectional fabrics.

Technical Specifications

This document outlines the key technical specifications of the product, detailing its material properties, mechanical strength, and performance characteristics according to various international test standards.

The material used is 100% Para-Aramid Fiber, known for its excellent durability and heat resistance. The fabric has a weight of approximately 260 ± 10 grams per square meter, as measured by ISO 3801. The weave type can be customized, offering options between plain and twill weaves to suit different application needs.

In terms of dimensions, the thickness ranges from around 0.35 to 0.40 millimeters in accordance with ISO 5084, and the width can be tailored between 100 and 160 centimeters. The fabric exhibits impressive tensile strength, with warp strength of at least 2,500 N per 5 cm and weft strength of no less than 2,200 N per 5 cm, verified under ISO 13934-1.

Tear strength is robust as well, measuring a minimum of 150 N for the warp direction and 130 N for the weft, tested via ISO 13937-2 standards. The Limiting Oxygen Index (LOI) is rated at 28% or greater, demonstrating good fire retardant properties as per ASTM D2863.

Operating temperature ranges continuously from -50°C up to +250°C, ensuring performance under extreme conditions. The decomposition temperature exceeds 500°C, confirmed by Thermogravimetric Analysis (TGA). In addition, the fabric is highly abrasion resistant, enduring at least 60,000 cycles in Martindale testing (ISO 12947-2).

The material also provides strong cut resistance, classified as EN388 Level D and ANSI A4 according to the EN388:2016 and ANSI 105 standards. Heat shrinkage is minimal, limited to no more than 1.5% after exposure to 250°C for 30 minutes. The natural color of the fabric is a golden yellow, although dyed options are available upon request.

Finally, the minimum order quantity is 500 meters, with negotiations available to accommodate specific purchasing requirements.

Industry Applications Overview

In the field of Personal Protective Equipment (PPE) , materials are utilized to create essential safety gear such as firefighter turnout gear outer shells, welding aprons, foundry suits, cut-resistant gloves and sleeves, as well as anti-slash clothing. These applications are crucial for safeguarding workers against various hazards in challenging environments.

The Ballistic and Armor  sector employs specialized materials for manufacturing bulletproof vest backing layers, spall liners, helmet shells, and vehicle armor spall guards. These components play a vital role in enhancing protection for , law enforcement, and security personnel.

In Industrial Filtration , high-temperature dust filter bags and hot gas filtration media are commonly used, particularly within cement, steel, and incineration plants. These filtration systems help maintain cleaner air by efficiently capturing particulate matter.

The Automotive and Aerospace industries benefit from materials applied in brake pad reinforcement, clutch facings, gaskets, thermal insulation blankets, and composite structural layers. These applications contribute to improved performance, safety, and durability of vehicles and aircraft.

For Friction and Sealing purposes, industrial gaskets, expansion joints, compensators, and high-temperature conveyor belts are manufactured using specialized fabrics and composites. These elements ensure reliable sealing and effective handling of high-temperature processes.

In the area of Composite Reinforcement , prepreg base fabrics are used for carbon-aramid hybrid composites, honeycomb core face sheets, as well as sporting goods including skis, surfboards, and racing hulls. These materials enhance strength and reduce weight in advanced composite constructions.

Finally, Electrical Insulation applications include transformer coil wrapping, motor slot liners, and high-temperature cable wraps. These insulation materials are essential for protecting electrical components and ensuring their efficient and safe operation under demanding conditions.

Our Para Aramid Fabric, model number Tdzpaw260, is a high-quality aramid fabric manufactured in China, certified to meet EN 11612 standards. This fire proof fabric offers excellent thermal stability up to 260℃ with only 1.5% dimensional change, zero after flame time, and a water washing dimensional change rate of 3%, ensuring durability and reliable performance.

As a trusted kevlar fabric alternative, our Para Aramid Fabric is supplied in rolls of about 100 meters, with a minimum order quantity of 1000 meters. Priced competitively at 12 dollars per meter, we can supply up to 3000 meters per day with a delivery time of 30 days. Payment terms are T/T for your convenience.

Please note, the fabric has a pH value between 5-7 and light fastness rated as bad, which should be considered based on your application requirements. Choose our Para Aramid Fabric for superior fire proof fabric solutions backed by certified quality and reliable supply ability.

Our Para Aramid Fabric product is designed to provide exceptional strength, durability, and resistance for various industrial applications. To ensure optimal performance and longevity, please follow the recommended handling and maintenance guidelines.

When handling Para Aramid Fabric, avoid exposure to strong acids, alkalis, and prolonged sunlight to prevent degradation. Always store the fabric in a cool, dry place away from direct sunlight and moisture.

For cutting and sewing, use sharp tools to achieve clean edges and prevent fraying. It is advisable to use protective gloves to avoid skin irritation during handling.

Cleaning of Para Aramid Fabric should be done with mild detergents and lukewarm water. Avoid using bleach or harsh chemicals. Air drying is recommended; do not use high heat or direct flame as it may damage the fibers.

If you encounter any issues or require technical assistance, our support team is available to provide guidance on product selection, application techniques, and troubleshooting.

We are committed to ensuring the highest quality and customer satisfaction. For additional information on product specifications, certifications, or customized solutions, please refer to the product datasheet or contact our technical support department.

Para Aramid Fabric is carefully packaged to ensure maximum protection during transportation. Each roll is tightly wound and wrapped in a moisture-resistant plastic film to prevent damage from humidity and contaminants. The wrapped fabric is then placed in sturdy cardboard tubes or boxes to maintain its shape and provide additional protection against physical impact.

For shipping, the packaged Para Aramid Fabric rolls are securely placed on pallets and strapped to avoid movement during transit. Depending on the destination and order size, shipments can be made via air, sea, or land freight. All packages are clearly labeled with product information, handling instructions, and safety warnings to ensure proper handling throughout the supply chain.

We prioritize timely delivery and product integrity, working with reliable logistics partners to guarantee that your Para Aramid Fabric arrives in excellent condition and on schedule.

Q1: What is the brand and model number of the Para Aramid Fabric?

A1: The brand name is Para Aramid, and the model number is Tdzpaw260.

Q2: Where is the Para Aramid Fabric manufactured?

A2: The Para Aramid Fabric is manufactured in China.

Q3: What certification does the Para Aramid Fabric have?

A3: This fabric is certified with EN 11612, which ensures its protective properties.

Q4: What is the minimum order quantity and pricing for the Para Aramid Fabric?

A4: The minimum order quantity is 1000 meters, and the price is 12 dollars per meter.

Q5: How is the Para Aramid Fabric packaged and what is the typical delivery time?

A5: The fabric is packaged with about 100 meters per roll. The typical delivery time is 30 days.

Q6: What are the payment terms and supply ability for this product?

A6: Payment terms are T/T (Telegraphic Transfer), and the supply ability is 3000 meters per day.
