Product Description:
The material features inherent flame resistance with a Limiting Oxygen Index (LOI) of 28% or higher. It self-extinguishes immediately once the flame source is removed, exhibiting no melting, dripping, or afterglow. This performance surpasses the requirements of NFPA 701 and ASTM D6413 standards, ensuring permanent thermal protection that will not wash out or deteriorate over time.
Renowned for its exceptional tensile strength, this material boasts a value of at least 3.2 gigapascals, making it five times stronger than steel wire by weight. Such strength allows it to endure extreme mechanical stresses, rendering it ideal for high-tension applications including ballistic panels, conveyor belts, and structural reinforcements.
Its superior abrasion resistance is demonstrated by surviving 60,000 or more Martindale cycles. Designed for demanding wear conditions, the material provides three to five times the service life of conventional polyester or nylon fabrics in friction-intensive settings such as industrial sleeves, gaskets, and protective covers.
With high cut resistance rated at EN388 Level D and ANSI A4 to A5 equivalent, the material’s tightly woven structure effectively withstands slashing and cutting forces. This makes it particularly suitable for manufacturing protective gloves, sleeves, aprons, and shielding equipment used in metal fabrication, glass handling, and automotive sectors.
The material exhibits excellent thermal stability, capable of continuous operation at temperatures up to 250°C and able to withstand decomposition temperatures exceeding 500°C. It maintains its mechanical integrity under extreme heat without shrinking or degrading.
Additionally, it offers good chemical resistance against most organic solvents, oils, and acids, excluding concentrated sulfuric and nitric acids. This reliability in harsh chemical processing and filtration environments makes it a versatile choice for various industrial applications.
Despite its strength and durability, the material remains lightweight at 260 grams per square meter. This optimal strength-to-weight ratio allows it to be thin enough for use in multi-layer composite laminations while still robust enough to function effectively in standalone applications.
Features:
Para-aramid woven fabric weighing 260 gsm is considered the benchmark in the realm of high-performance industrial textiles. Crafted entirely from 100% para-aramid fibers, equivalent to Kevlar®-grade quality, this fabric offers a unique combination of qualities. It features inherent flame resistance, remarkable tensile strength, and exceptional abrasion resistance, all integrated into a lightweight material.
Different from flame-retardant fabrics that rely on surface treatments and tend to lose their effectiveness after multiple washes, the fire-resistant property of para-aramid is intrinsic and molecular. This characteristic is embedded within the polymer chain itself. When exposed to extreme heat, the fabric chars but does not melt, drip, or support combustion, providing consistent protection throughout its lifespan.
The 260 g/m² weight category achieves an optimal balance, being sufficiently heavy for rigorous protective uses while remaining light and flexible enough for comfortable wearable apparel and adaptable composite matrix applications. Additionally, its plain or twill weave structure ensures even strength distribution in both warp and weft directions, effectively reducing the directional weaknesses commonly found in unidirectional materials.
Technical Parameters:
Technical Specifications
The material used is 100% Para-Aramid Fiber, known for its outstanding strength and durability. This fabric has a weight of 260 ± 10 grams per square meter, measured according to ISO 3801 standards.
The weave type can be customized between plain and twill, offering flexibility depending on the application requirements. The fabric thickness ranges approximately from 0.35 to 0.40 millimeters, as determined by ISO 5084 testing methods.
Width options are customizable as well, ranging from 100 to 160 centimeters, allowing for versatile usage in different contexts.
In terms of mechanical properties, the tensile strength in the warp direction is at least 2,500 Newtons per 5 centimeters, while in the weft direction it is at least 2,200 Newtons per 5 centimeters, both tested according to ISO 13934-1 standards.
The fabric exhibits strong tear resistance, with values of no less than 150 Newtons in the warp and 130 Newtons in the weft, evaluated using ISO 13937-2 procedures.
The limiting oxygen index (LOI) is 28% or higher, based on ASTM D2863, indicating good flame-retardant properties. It can continuously operate at temperatures from -50°C up to +250°C, with a decomposition temperature exceeding 500°C as measured by TGA analysis.
Additional durability is demonstrated by a high abrasion resistance of at least 60,000 cycles in Martindale testing (ISO 12947-2), as well as superior cut resistance meeting EN388 Level D and ANSI A4 standards.
Heat shrinkage remains minimal, with a maximum of 1.5% after exposure to 250°C for 30 minutes. The natural fabric color is a golden yellow, though various dyed options are available to suit different preferences.
The minimum order quantity is set at 500 meters; however, this can be negotiated according to customer needs.
Applications:
Industry Applications
In the
Personal Protective Equipment (PPE)
sector, products include firefighter turnout gear outer shells, welding aprons, foundry suits, cut-resistant gloves and sleeves, as well as anti-slash clothing. These items are essential for ensuring safety and protection in hazardous environments.
The
Ballistic & Armor
industry utilizes materials for bulletproof vest backing layers, spall liners, helmet shells, and vehicle armor spall guards. These components play a critical role in providing ballistic protection and enhancing safety.
For
Industrial Filtration
, applications feature high-temperature dust filter bags and hot gas filtration media used in cement, steel, and incineration plants. Such filtration solutions help maintain air quality and operational efficiency under extreme conditions.
The
Automotive & Aerospace
sectors employ materials for brake pad reinforcement, clutch facings, gaskets, thermal insulation blankets, and composite structural layers, contributing to improved performance and durability in vehicles and aircraft.
In
Friction & Sealing
applications, industrial gaskets, expansion joints, compensators, and high-temperature conveyor belts are prominent. These products are designed to withstand mechanical stress and high thermal environments.
The
Composite Reinforcement
industry uses prepreg base fabric for carbon-aramid hybrid composites, honeycomb core face sheets, and sporting goods such as skis, surfboards, and racing hulls. These materials enhance strength and reduce weight in various products.
Lastly,
Electrical Insulation
applications include transformer coil wrapping, motor slot liners, and high-temperature cable wraps. These components are vital for safe and reliable electrical system operation under demanding conditions.
Customization:
Our Para Aramid Fabric product, model number Tdzpaw260, offers exceptional quality and customization services tailored to your needs. Originating from China and certified with EN 11612, this aramid fabric is designed to provide superior protection and durability.
We specialize in customizing anti cut fabric with a style of 2/1 twill, ensuring optimal performance for various applications. The fabric has a pH value of 5-7 and does not produce melted droplets, making it safe and reliable for protective gear manufacturing.
Each roll is packaged with about 100 meters in a nylon bag to preserve fabric integrity. Our minimum order quantity is 1000 meters, priced competitively at 12 dollars per meter, with a supply ability of 3000 meters per day to meet large-scale demands efficiently.
Delivery time is approximately 30 days, and payment terms are flexible via T/T. Please note that the fabric has a light fastness rating of bad, which should be considered in your application environment.
Choose our Para Aramid aramid fabric for your next project to benefit from high-quality anti cut fabric that combines safety, durability, and customization to meet your exact specifications.
Support and Services:
Our Para Aramid Fabric product is designed to offer exceptional strength, durability, and resistance to heat and abrasion, making it ideal for a wide range of industrial and protective applications. To ensure optimal performance and longevity, proper handling and maintenance are essential.
When handling Para Aramid Fabric, avoid exposure to strong acids, alkalis, and prolonged ultraviolet light, as these can degrade the material's properties. It is recommended to store the fabric in a cool, dry place away from direct sunlight and sources of heat.
For cleaning, use mild detergents and cold water, and avoid using bleach or harsh chemicals. Do not machine wash or tumble dry, as mechanical agitation and high temperatures can damage the fibers. Instead, gently hand wash and air dry the fabric flat to maintain its integrity.
In case of any issues or for technical assistance, please refer to the product datasheet and safety guidelines provided with the fabric. Our technical support team is available to help with application advice, customization options, and troubleshooting to ensure you get the best results from your Para Aramid Fabric.
We are committed to providing high-quality products and services to support your needs. For further information on product specifications, certifications, or to request technical documentation, please consult our website or authorized representatives.
Packing and Shipping:
Our Para Aramid Fabric is carefully packaged to ensure maximum protection during transit. Each roll is tightly wound and wrapped in a protective plastic film to prevent moisture and dust contamination. The fabric rolls are then placed in sturdy, reinforced cardboard tubes or boxes to maintain shape and avoid damage.
For shipping, we use reliable and secure methods tailored to the destination and order size. Packages are clearly labeled with handling instructions and tracking information. We offer various shipping options including standard, expedited, and freight services to meet customer needs worldwide. Our logistics partners ensure timely delivery while maintaining the integrity of the product throughout the shipping process.
FAQ:
Q1: What is the brand and model number of this Para Aramid Fabric?
A1: The fabric is branded as Para Aramid and the model number is Tdzpaw260.
Q2: Where is the Para Aramid Fabric manufactured?
A2: This fabric is produced in China.
Q3: Does this Para Aramid Fabric have any certifications?
A3: Yes, it is certified with EN 11612, which indicates its compliance for protective clothing against heat and flame.
Q4: What is the minimum order quantity and price per meter?
A4: The minimum order quantity is 1000 meters, and the price is 12 dollars per meter.
Q5: How is the Para Aramid Fabric packaged and what is the delivery time?
A5: The fabric is packaged approximately 100 meters per roll, and the delivery time is 30 days.
Q6: What payment terms are accepted and what is the supply capacity?
A6: Payment is accepted via T/T (telegraphic transfer), and the supply ability is 3000 meters per day.
