Product Description:
The material boasts an inherent flame resistance with a Limiting Oxygen Index (LOI) of 28% or higher. It is self-extinguishing once the flame source is removed, exhibiting no melting, dripping, or afterglow. This characteristic surpasses the requirements set by NFPA 701 and ASTM D6413 standards, offering permanent thermal protection that does not wash out or degrade over time.
In terms of mechanical strength, the fabric delivers exceptional tensile strength of at least 3.2 GPa. This makes it five times stronger than steel wire of the same weight, allowing it to endure intense mechanical stress. Such robustness makes it ideal for demanding applications like ballistic panels, conveyor belts, and structural reinforcements.
The abrasion resistance of this material is equally impressive, achieving 60,000 or more Martindale cycles. Designed for heavy-duty wear conditions, it provides three to five times longer service life compared to traditional polyester or nylon fabrics. This makes it especially suitable for friction-heavy uses such as industrial sleeves, gaskets, and protective covers.
The fabric’s high cut resistance, classified as EN388 Level D and equivalent to ANSI A4–A5 standards, results from its tightly woven structure. This feature protects against slashing and cutting damage, making the material an excellent choice for protective gloves, sleeves, aprons, and shielding equipment used in metal fabrication, glass handling, and automotive sectors.
Additionally, the material offers excellent thermal stability with continuous operating temperatures up to 250°C and decomposition temperatures exceeding 500°C. It maintains its mechanical properties even under extreme heat, showing no signs of shrinkage or degradation.
It also exhibits resistance to a broad range of chemicals, including most organic solvents, oils, and acids, though it is not resistant to concentrated sulfuric and nitric acids. This chemical resilience ensures reliable performance in tough chemical processing and filtration applications.
Despite its strong and durable properties, the fabric remains lightweight at 260 grams per square meter. This weight strikes an optimal balance between strength and flexibility, allowing it to be used both as a thin layer in multi-layer composite laminates and as a tough standalone fabric in various uses.
Features:
Para-aramid woven fabric with a weight of 260 gsm is considered the benchmark in high-performance industrial textiles. Made entirely from 100% para-aramid fibers, comparable to Kevlar®, this fabric offers a unique combination of inherent flame resistance, exceptional tensile strength, and outstanding abrasion resistance, all within a lightweight design.
Unlike flame-retardant fabrics that rely on chemical treatments and may lose their protective properties after multiple washes, the fire resistance of para-aramid is intrinsic at the molecular level. This characteristic is embedded directly into the polymer chains, meaning the fabric will char when exposed to extreme heat but will never melt, drip, or catch fire. This ensures dependable protection throughout the product's entire lifespan.
The 260 gsm weight category provides an optimal balance between durability and comfort. It is robust enough for demanding protective applications yet remains lightweight and flexible enough for use in wearable safety gear and adaptable composite materials. Additionally, the plain or twill weave pattern offers consistent strength in both the warp and weft directions, effectively reducing the directional weaknesses often found in unidirectional fabrics.
Technical Parameters:
Technical Specifications
This product is made from 100% Para-Aramid Fiber, ensuring high durability and strength. The material boasts a weight of approximately 260 grams per square meter, with a slight variance of ±10 g/m², tested according to ISO 3801 standards.
The fabric's weave type can be customized between plain and twill weaves to suit different application needs. Its thickness ranges from roughly 0.35 to 0.40 millimeters, measured by ISO 5084, offering a balanced combination of flexibility and protection. Width options vary between 100 and 160 centimeters, also customizable based on requirements.
For mechanical properties, the tensile strength in the warp direction is at least 2,500 Newtons per 5 centimeters, while in the weft direction it is at least 2,200 Newtons per 5 centimeters, as per ISO 13934-1 testing methods. Tear strength reaches a minimum of 150 Newtons in the warp direction and 130 Newtons in the weft, measured according to ISO 13937-2.
The material exhibits a Limiting Oxygen Index (LOI) of 28% or higher, tested by ASTM D2863, which indicates good flame resistance. It can withstand continuous operating temperatures ranging from -50°C up to +250°C, and decomposition temperatures exceed 500°C, confirmed by Thermogravimetric Analysis (TGA).
Further durability is proven through abrasion resistance, passing at least 60,000 cycles per the Martindale test (ISO 12947-2). It also offers excellent cut resistance, compliant with EN388 Level D and ANSI A4 standards. Heat shrinkage remains minimal, not exceeding 1.5% after exposure to 250°C for 30 minutes.
The standard color is a natural golden yellow, although dyed options can be made available upon request. The minimum order quantity is typically 500 meters, with negotiation possible for different quantities.
Applications:
The use of Personal Protective Equipment (PPE) spans various critical safety gear including firefighter turnout gear outer shells, welding aprons, foundry suits, cut-resistant gloves and sleeves, as well as anti-slash clothing designed to protect workers in hazardous environments.
In the realm of Ballistic and Armor applications, materials are employed for backing layers in bulletproof vests, spall liners, helmet shells, and vehicle armor spall guards, providing enhanced protection against ballistic threats.
Industrial Filtration applications involve high-temperature dust filter bags and hot gas filtration media that are used in demanding settings such as cement plants, steel manufacturing facilities, and incineration plants, ensuring effective filtration under extreme conditions.
The Automotive and Aerospace industries utilize these materials for brake pad reinforcement, clutch facings, gaskets, thermal insulation blankets, and composite structural layers, all contributing to improved performance and durability in vehicles and aircraft.
In Friction and Sealing applications, the materials serve in manufacturing industrial gaskets, expansion joints, compensators, and high-temperature conveyor belts, which are essential components in maintaining operational efficiency across various machinery.
Composite Reinforcement is another key area, where prepreg base fabrics for carbon-aramid hybrid composites are used. Additionally, these materials find applications as honeycomb core face sheets and in sporting goods such as skis, surfboards, and racing hulls, enhancing strength and lightweight characteristics.
Finally, Electrical Insulation applications include transformer coil wrapping, motor slot liners, and high-temperature cable wraps, all crucial for ensuring reliable electrical performance and safety in high-temperature environments.
Customization:
Our Para Aramid Fabric, model number Tdzpaw260, is a premium anti cut fabric designed to meet high safety and durability standards. Originating from China, this para aramid fabric is certified with EN 11612, ensuring excellent thermal protection with a thermal stability of 260℃ at 1.5%.
We offer this para aramid fabric in a 2/1 TWILL style with a width of 150cm, providing a break strength of 2800/2500N and an after flame time of 0 seconds, making it ideal for protective garments and industrial applications.
The minimum order quantity is 1000 meters, priced at 12 dollars per meter. Packaging is done with approximately 100 meters per roll for convenient handling. With a supply ability of 3000 meters per day, we guarantee timely delivery within 30 days. Payment terms are T/T for your convenience.
Choose our Para Aramid Fabric for superior anti cut fabric solutions that combine strength, thermal resistance, and reliability.
Support and Services:
Our Para Aramid Fabric product is designed to deliver exceptional strength, durability, and resistance to heat and abrasion, making it ideal for a wide range of industrial and protective applications. To ensure optimal performance and longevity of the fabric, please follow the recommended handling and maintenance guidelines.
When cutting or sewing Para Aramid Fabric, use sharp tools to prevent fraying and maintain fabric integrity. It is advisable to wear protective gloves to avoid irritation from loose fibers. For bonding or laminating, use adhesives compatible with high-performance fibers to achieve the best results.
Cleaning should be done with mild detergents and cold water to preserve the fabric’s properties. Avoid bleach, strong chemicals, and high-temperature washing or drying processes, as these can degrade the fibers. Air drying is recommended to maintain the fabric’s strength and flexibility.
Storage of Para Aramid Fabric should be in a cool, dry place away from direct sunlight and sources of heat or moisture. Keep the fabric rolled or flat to avoid creasing or deformation that could impact its performance.
If you encounter any issues with the product or require technical assistance, our support team is available to provide guidance on application techniques, customization options, and troubleshooting. We are committed to helping you maximize the benefits of our Para Aramid Fabric through expert advice and tailored solutions.
Packing and Shipping:
Our Para Aramid Fabric is carefully packaged to ensure maximum protection during transit. Each roll is tightly wound and wrapped in a protective plastic film to prevent moisture, dust, and contamination. The wrapped rolls are then securely placed in sturdy cardboard boxes or wooden crates, depending on the order size and shipping requirements.
For shipping, we use reliable carriers experienced in handling industrial textiles to guarantee timely and safe delivery. All packages are clearly labeled with product details, handling instructions, and destination information. We also offer customized packaging solutions upon request to meet specific customer needs.
Whether shipped domestically or internationally, our Para Aramid Fabric packaging is designed to maintain product integrity, ensuring you receive the fabric in excellent condition, ready for immediate use.
FAQ:
Q1: What is the brand and model number of this Para Aramid Fabric?
A1: The brand name is Para Aramid and the model number is Tdzpaw260.
Q2: Where is the Para Aramid Fabric manufactured?
A2: This fabric is produced in China.
Q3: What certification does the Para Aramid Fabric have?
A3: The fabric is certified with EN 11612, ensuring its protective qualities.
Q4: What is the minimum order quantity and price per meter?
A4: The minimum order quantity is 1000 meters, and the price is 12 dollars per meter.
Q5: How is the fabric packaged and what is the delivery time?
A5: The fabric is packaged in rolls of about 100 meters each, with a delivery time of 30 days.
Q6: What are the payment terms and supply ability for this product?
A6: Payment is accepted via T/T, and the supply ability is 3000 meters per day.
