Product Description:
The material features inherent flame resistance with a Limiting Oxygen Index (LOI) of 28% or higher. It self-extinguishes immediately once the flame source is removed, producing no melting, dripping, or afterglow. This performance surpasses the NFPA 701 and ASTM D6413 standards, ensuring permanent thermal protection that does not wash out or degrade over time.
It boasts exceptional tensile strength measuring at least 3.2 GPa, making it five times stronger than steel wire by weight. This impressive durability enables it to endure extreme mechanical stresses found in high-tension uses such as ballistic panels, conveyor belts, and structural reinforcements.
With superior abrasion resistance of at least 60,000 Martindale cycles, the fabric is engineered to withstand heavy-duty wear environments. It offers a service life three to five times longer than traditional polyester or nylon fabrics, especially in friction-intensive applications like industrial sleeves, gaskets, and protective covers.
The material also provides high cut resistance, rated at EN388 Level D and equivalent to ANSI A4–A5 standards. Its tightly woven structure is designed to resist slashing and cutting, making it ideal for protective equipment such as gloves, sleeves, aprons, and shielding used in metal fabrication, glass handling, and automotive industries.
It demonstrates excellent thermal stability, with a continuous operating temperature of up to 250°C and a decomposition temperature exceeding 500°C. The material maintains its mechanical integrity under extreme heat conditions without shrinking or degrading.
Chemical resistance is another key feature, showing good tolerance to most organic solvents, oils, and acids, except for concentrated sulfuric and nitric acids. This makes it reliable for use in demanding chemical processing and filtration environments.
Despite its strength and durability, the material remains lightweight at 260 grams per square meter. This weight offers an optimal balance between strength and weight, being thin enough for use in multi-layer composite laminations while still robust enough for standalone applications.
Features:
The para-aramid woven fabric with a weight of 260 gsm is recognized as the benchmark in the realm of high-performance industrial textiles. Crafted entirely from 100% para-aramid fibers, comparable to Kevlar® grade, this material seamlessly integrates innate flame resistance, exceptional tensile strength, and outstanding abrasion durability into a single, lightweight fabric.
In contrast to flame-retardant fabrics that rely on treatments and can lose their effectiveness after multiple washes, para-aramid's fire-resistant properties are intrinsic, embedded at the molecular level within the polymer chains. When exposed to extreme heat, the fabric chars rather than melting, dripping, or igniting, thereby providing consistent and dependable protection throughout the lifespan of the product.
At a weight of 260 grams per square meter, this fabric offers the perfect compromise between robustness and flexibility. It is sufficiently heavy to meet the demands of rigorous protective applications, yet remains lightweight and supple enough to be used comfortably in wearable gear and adaptable composite materials. Its plain or twill weave structure ensures balanced strength along both the warp and weft directions, reducing the directional weaknesses commonly found in unidirectional fabrics.
Technical Parameters:
Technical Specifications
This product is made from 100% Para-Aramid Fiber, ensuring high durability and strength suitable for various demanding applications. The material provides a natural golden yellow color, with options available for customization through dyeing.
The fabric has a weight of approximately 260 ± 10 grams per square meter, conforming to the ISO 3801 standard. It features a customizable weave type, either plain or twill, allowing flexibility to meet specific performance requirements.
With a thickness ranging from approximately 0.35 to 0.40 millimeters (measured according to ISO 5084), this fabric balances lightweight characteristics with substantial strength and durability. The width can be tailored between 100 and 160 centimeters to accommodate different usage needs.
The tensile strength of the fabric is notably high, achieving a minimum of 2,500 newtons per 5 centimeters in the warp direction and 2,200 newtons per 5 centimeters in the weft direction, following ISO 13934-1 standards. Additionally, tear strength reaches at least 150 newtons for warp and 130 newtons for weft, as certified by ISO 13937-2.
Safety and resistance properties are also prominent, with a Limiting Oxygen Index (LOI) of at least 28% according to ASTM D2863, making it resistant to combustion. The fabric withstands continuous operating temperatures from -50°C to +250°C and does not decompose until exceeding 500°C, verified by TGA analysis.
Furthermore, the fabric offers excellent abrasion resistance, capable of enduring over 60,000 cycles as measured by the Martindale method (ISO 12947-2). Its cut resistance meets EN388 Level D and ANSI A4 standards, confirming its reliability in protective environments. Heat shrinkage is minimal, limited to a maximum of 1.5% after exposure to 250°C for 30 minutes.
Minimum order quantity starts at 500 meters; however, this requirement can be negotiated to suit different customer needs.
Applications:
Personal Protective Equipment (PPE)
This category includes applications such as firefighter turnout gear outer shells, welding aprons, foundry suits,
cut-resistant gloves and sleeves, as well as anti-slash clothing. These products are designed to offer enhanced protection
in hazardous environments.
Ballistic & Armor
In the ballistic and armor industry, materials are used for bulletproof vest backing layers, spall liners, helmet shells,
and vehicle armor spall guards. These applications focus on providing safety and durability against high-impact threats.
Industrial Filtration
Industrial filtration makes use of high-temperature dust filter bags and hot gas filtration media. These are commonly applied
in sectors like cement, steel production, and incineration plants to ensure cleaner air and safer working conditions.
Automotive & Aerospace
The automotive and aerospace fields employ materials for brake pad reinforcement, clutch facings, gaskets, thermal insulation
blankets, and composite structural layers. These components contribute to the performance, efficiency, and safety of vehicles and aircraft.
Friction & Sealing
Applications in friction and sealing include industrial gaskets, expansion joints, compensators, and high-temperature conveyor belts.
These products are critical for maintaining equipment integrity and operational reliability under extreme conditions.
Composite Reinforcement
Composite reinforcement involves the use of prepreg base fabric for carbon-aramid hybrid composites, honeycomb core face sheets,
and sporting goods such as skis, surfboards, and racing hulls. These materials enhance strength while reducing weight.
Electrical Insulation
In electrical insulation, materials are utilized for transformer coil wrapping, motor slot liners, and high-temperature cable wrap.
These applications ensure electrical safety and performance in demanding environments.
Customization:
Our Para Aramid Fabric, model number Tdzpaw260, offers exceptional customization services tailored to meet your specific needs. Manufactured in China and certified to EN 11612 standards, this aramid fabric is designed for high performance and durability. We supply staple para aramid fiber in a raw yellow color, with a level 3 anti-cut rating, making it ideal for protective applications.
The kevlar fabric is available at a competitive price of 12 dollars per meter, with a minimum order quantity of 1000 meters. Each roll is packaged with approximately 100 meters, securely packed in nylon bags to ensure product integrity during transit. Our production capacity allows us to supply up to 3000 meters per day, with a delivery time of 30 days after order confirmation.
Payment terms are flexible with T/T accepted for your convenience. Please note that the light fastness of this kevlar fabric is rated as bad, so it is best suited for applications where prolonged exposure to light is minimal. Trust our Para Aramid Fabric customization services to provide you with reliable, high-quality aramid fabric solutions tailored to your project requirements.
Support and Services:
Our Para Aramid Fabric product is backed by comprehensive technical support and services to ensure optimal performance and customer satisfaction. Our team of experts is available to provide assistance with product selection, application guidance, and troubleshooting to meet your specific needs.
We offer detailed product documentation, including technical datasheets, safety information, and handling instructions to help you understand the capabilities and limitations of our Para Aramid Fabric. Additionally, we provide custom testing services to validate the fabric’s performance under various conditions.
For customers requiring tailored solutions, we offer customization options and collaborative support during the design and development phases. Our technical support team is committed to delivering timely and effective solutions to maximize the benefits of using Para Aramid Fabric in your applications.
Ongoing training and educational resources are available to keep your team informed about the latest advancements and best practices related to Para Aramid Fabric. By choosing our product, you gain access to a dedicated support network that prioritizes your success and product reliability.
Packing and Shipping:
Our Para Aramid Fabric is carefully packaged to ensure maximum protection during transit. Each roll is tightly wound and wrapped with a protective film to prevent moisture, dust, and damage. The fabric rolls are then securely placed in sturdy cardboard tubes or boxes, reinforced with cushioning materials as needed to maintain product integrity.
For shipping, we use reliable carriers and provide tracking information to our customers. The packaging is designed to withstand handling and environmental factors, ensuring that the Para Aramid Fabric arrives in excellent condition and ready for immediate use.
FAQ:
Q1: What is the model number of the Para Aramid Fabric?
A1: The model number of the Para Aramid Fabric is Tdzpaw260.
Q2: Where is the Para Aramid Fabric manufactured?
A2: The Para Aramid Fabric is made in China.
Q3: What certification does the Para Aramid Fabric have?
A3: This fabric is certified with EN 11612, ensuring it meets protective clothing standards.
Q4: What is the minimum order quantity and price per meter?
A4: The minimum order quantity is 1000 meters, and the price is 12 dollars per meter.
Q5: How is the Para Aramid Fabric packaged and what is the typical delivery time?
A5: The fabric is packaged with about 100 meters per roll, and the delivery time is approximately 30 days.
Q6: What are the payment terms and supply capacity for the Para Aramid Fabric?
A6: Payment is accepted via T/T, and the supply ability is 3000 meters per day.
