Tear Strength 152 200N Anti Cut Fabric Fabric for Protective Workwear and Safety Equipment in Heavy Duty Industrial Settings

Product Description:

This material possesses inherent flame resistance with a Limiting Oxygen Index (LOI) of 28% or higher. It is self-extinguishing once the flame source is removed, ensuring no melting, dripping, or afterglow occurs. It surpasses the stringent NFPA 701 and ASTM D6413 standards, offering permanent thermal protection that neither washes out nor degrades over time.

The fabric demonstrates exceptional tensile strength, measuring at least 3.2 GPa, which is approximately five times stronger than steel wire when compared on an equal-weight basis. This remarkable strength allows it to endure extreme mechanical stresses in demanding applications such as ballistic panels, conveyor belts, and structural reinforcements.

With superior abrasion resistance, achieving no less than 60,000 Martindale cycles, the material is designed for use in heavy-duty wear environments. It provides a service life that is three to five times longer than traditional polyester or nylon fabrics, making it ideal for friction-intensive uses including industrial sleeves, gaskets, and protective covers.

Offering high cut resistance, classified as EN388 Level D and equivalent to ANSI A4–A5 standards, the tightly woven structure effectively resists slashing and cutting hazards. This makes it an excellent choice for protective gloves, sleeves, aprons, and equipment shielding in industries such as metal fabrication, glass handling, and automotive manufacturing.

The material exhibits excellent thermal stability, capable of continuous operation at temperatures up to 250°C and decomposition temperatures exceeding 500°C. It maintains its mechanical integrity even in extreme heat environments without shrinking or degrading, ensuring reliable performance under harsh thermal conditions.

Additionally, it offers good chemical resistance against most organic solvents, oils, and acids, with the exception of concentrated sulfuric and nitric acids. This characteristic makes it suitable for use in harsh chemical processing and filtration applications.

Weighing only 260 grams per square meter, this lightweight fabric strikes an optimal balance between strength and weight. It is thin enough to be used in multi-layer composite laminations while remaining robust enough for standalone applications.

Features:

Para-aramid woven fabric with a weight of 260 gsm is widely regarded as the benchmark in high-performance industrial textiles. Crafted entirely from 100% para-aramid fibers, which are equivalent to Kevlar® grade, this fabric merges innate flame resistance, exceptional tensile strength, and excellent abrasion resistance into a single lightweight material.

Unlike flame-retardant fabrics that rely on chemical treatments and gradually lose their protective qualities after repeated washes, para-aramid's fire resistance is inherent at a molecular level. This resistance is integrated directly into the polymer chains of the fibers. When exposed to extreme heat, the fabric chars instead of melting or dripping, and it does not support combustion. This ensures consistent and dependable protection over the entire lifespan of the product.

Weighing in at 260 g/m², this fabric achieves the perfect balance between durability and comfort. It is robust enough to meet the strict demands of protective applications but remains light and flexible enough for use in wearable protective gear and adaptable composite materials. Moreover, its plain or twill weave design provides even strength distribution across both the warp and weft directions, effectively reducing weaknesses often found in unidirectional fabrics.

Technical Parameters:

The material used in this product is 100% Para-Aramid Fiber, ensuring high durability and performance. It has a weight of approximately 260 ± 10 grams per square meter, measured according to the ISO 3801 standard. The fabric weave can be customized to either plain or twill patterns, allowing flexibility based on specific requirements.

The thickness of the fabric ranges from approximately 0.35 to 0.40 millimeters, tested following ISO 5084. Width options are customizable between 100 and 160 centimeters, catering to diverse application needs. For strength, the tensile strength in the warp direction is at least 2,500 Newtons per 5 centimeters, while in the weft direction it is no less than 2,200 Newtons per 5 centimeters, both tested under the ISO 13934-1 standard.

Regarding tear resistance, the fabric offers robust performance with a minimum tear strength of 150 Newtons along the warp and 130 Newtons along the weft, as per ISO 13937-2. The Limiting Oxygen Index (LOI) is 28% or higher, indicating good flame resistance according to ASTM D2863. This fabric can operate continuously in temperatures ranging from -50°C to +250°C, and it decomposes at temperatures above 500°C, established through Thermogravimetric Analysis (TGA).

Additional durability features include abrasion resistance of at least 60,000 cycles, tested using the Martindale method (ISO 12947-2). The fabric also provides cut resistance rated at EN388 Level D and ANSI A4 standards, meeting the EN388:2016 and ANSI 105 certification requirements. Heat shrinkage is controlled at a maximum of 1.5% when exposed to 250°C for 30 minutes.

The natural color of the material is a golden yellow, with options available for dyeing according to client preferences. The minimum order quantity is set at 500 meters, but this number is negotiable to accommodate different purchasing needs.

Applications:

Customization:

Our Para Aramid Fabric, model number Tdzpaw260, is a premium fire proof fabric designed for high-performance applications such as firefighter gear. Originating from China and certified with EN 11612, this kevlar fabric ensures excellent protection with an after flame time of 0 seconds and no melted droplet, enhancing safety in extreme conditions.

With a thickness of 0.3mm, this kevlar fabric is both durable and lightweight. Each roll contains about 100 meters, packaged securely in a nylon bag to maintain quality during transit. We offer a competitive price of 12 dollars per meter, with a minimum order quantity of 1000 meters.

Our supply ability is 3000 meters per day, ensuring timely fulfillment of orders with a delivery time of approximately 30 days. Payment terms are flexible with T/T accepted. Choose our Para Aramid fire proof fabric for reliable, certified protection and exceptional performance.

Support and Services:

Our Para Aramid Fabric product is designed to provide exceptional strength, durability, and heat resistance for a wide range of industrial applications. To ensure optimal performance and longevity of the fabric, please follow the recommended handling and maintenance guidelines.

Handling: Avoid excessive bending or folding of the fabric to prevent damage to the fibers. Use protective gloves when handling to minimize contamination and preserve fabric integrity.

Cleaning: Clean the Para Aramid Fabric using mild detergent and cold water. Do not use bleach or harsh chemicals as they can degrade the fibers. Air dry the fabric away from direct sunlight and high heat sources.

Storage: Store the fabric in a cool, dry place away from direct sunlight and moisture. Keep the fabric rolled or flat to avoid creases and deformation.

Inspection: Regularly inspect the fabric for any signs of wear, abrasion, or damage. Replace the fabric immediately if any significant deterioration is observed to maintain safety and performance standards.

For technical support, guidance on product applications, or additional services such as custom cutting and coating, our technical team is available to assist you with expert advice tailored to your specific requirements.

Packing and Shipping:

The Para Aramid Fabric is carefully rolled and wrapped in protective plastic to prevent moisture and contamination during transit.

Each roll is then securely packed in sturdy cardboard tubes or boxes to ensure stability and prevent damage.

For bulk orders, multiple rolls are placed on pallets and wrapped with stretch film to maintain integrity throughout shipping.

All packages are clearly labeled with product details, handling instructions, and shipping information to facilitate smooth delivery.

We offer various shipping options including air, sea, and land freight to meet your timeline and budget requirements.

Our logistics team ensures timely dispatch and tracking support until the Para Aramid Fabric reaches your designated location safely.

FAQ:

Q1: What is the brand and model number of the Para Aramid Fabric?

A1: The brand name is Para Aramid, and the model number is Tdzpaw260.

Q2: Where is the Para Aramid Fabric manufactured?

A2: The Para Aramid Fabric is produced in China.

Q3: What certification does the Para Aramid Fabric have?

A3: This fabric is certified under EN 11612, ensuring its performance and safety standards.

Q4: What is the minimum order quantity and pricing for this fabric?

A4: The minimum order quantity is 1000 meters, priced at 12 dollars per meter.

Q5: How is the Para Aramid Fabric packaged and what is the typical delivery time?

A5: The fabric is packaged with about 100 meters per roll, and the delivery time is approximately 30 days.

Q6: What are the payment terms and supply ability for the Para Aramid Fabric?

A6: Payment is accepted via T/T, and the supply ability is up to 3000 meters per day.
