Product Description:
The material demonstrates
inherent flame resistance
with a Limiting Oxygen Index (LOI) of 28% or higher. It self-extinguishes immediately once the flame source is removed, exhibiting no melting, dripping, or afterglow. This level of flame resistance surpasses the requirements set by both NFPA 701 and ASTM D6413 standards. As a result, it offers permanent thermal protection that remains effective indefinitely, without any loss or degradation over time.
Featuring
exceptional tensile strength
of at least 3.2 GPa, this material is approximately five times stronger than steel wire when compared on an equal weight basis. This remarkable strength enables it to endure substantial mechanical stresses, making it particularly suitable for demanding, high-tension applications like ballistic panels, conveyor belts, and structural reinforcements.
The fabric is also engineered for
superior abrasion resistance
, capable of withstanding 60,000 or more Martindale cycles. It offers three to five times the service life of traditional polyester or nylon fabrics in environments characterized by intense friction. Typical uses include industrial protective sleeves, gaskets, and covers, where durability is critical.
In terms of safety, the material provides
high cut resistance
, rated at EN388 Level D and the equivalent of ANSI A4 to A5. Its densely woven construction effectively resists slashing and cutting, making it an excellent choice for protective gear such as gloves, sleeves, aprons, and shielding solutions used in metal fabrication, glass handling, and automotive manufacturing.
The product exhibits
excellent thermal stability
, withstanding continuous operating temperatures up to 250°C and a decomposition temperature exceeding 500°C. This ensures that it maintains mechanical strength and integrity even under extreme heat conditions, resisting shrinkage and degradation.
Additionally, the material shows good
chemical resistance
against a wide range of organic solvents, oils, and acids. However, it does not tolerate concentrated sulfuric or nitric acids. It performs reliably in harsh chemical processing and filtration environments where chemical exposure is common.
Despite its robustness, the material remains
lightweight
at just 260 grams per square meter. This weight offers an optimal balance between strength and lightness, making it thin enough for multi-layer composite lamination yet durable enough for use as a standalone material in various applications.
Features:
Para-aramid woven fabric with a weight of 260 grams per square meter (gsm) is recognized as the benchmark for high-performance industrial textiles. Manufactured entirely from 100% para-aramid fibers, equivalent in quality to Kevlar®, this fabric uniquely blends intrinsic flame resistance, exceptional tensile strength, and outstanding abrasion resistance, all within a lightweight structure.
Unlike flame-retardant fabrics that rely on surface treatments and tend to lose effectiveness after multiple washes, the fire resistance of para-aramid is integrated at the molecular level, embedded within the polymer chains. When exposed to extreme heat, the fabric chars rather than melts or drips, and it does not support combustion. This guarantees dependable protection throughout the entire lifespan of the product.
The 260 gsm weight category offers an optimal compromise: it is sufficiently heavy to meet the requirements of demanding protective applications, yet remains light and flexible enough for comfortable wearable gear and adaptable composite materials. Additionally, its plain or twill weave structure provides consistent strength along both the warp and weft directions, thereby reducing the directional weaknesses commonly found in materials with unidirectional fibers.
Technical Parameters:
Technical Specifications
This product is made from 100% Para-Aramid Fiber, ensuring high durability and performance. The material's weight is approximately 260 grams per square meter, with a tolerance of ±10 g/m², measured according to the ISO 3801 standard.
The fabric features a customizable weave type, available in either plain or twill patterns. Its thickness ranges from approximately 0.35 to 0.40 millimeters, tested according to ISO 5084. The width of the fabric can be tailored between 100 and 160 centimeters to meet specific requirements.
In terms of strength, the tensile strength in the warp direction is at least 2,500 Newtons per 5 centimeters, and in the weft direction, it is no less than 2,200 Newtons per 5 centimeters. These values comply with the ISO 13934-1 standard. The tear strength is also robust, with minimum values of 150 Newtons (warp) and 130 Newtons (weft), as per ISO 13937-2 measurements.
The fabric boasts a Limiting Oxygen Index (LOI) of 28% or higher, demonstrating excellent flame resistance according to ASTM D2863. It can continuously operate within a temperature range of -50°C to +250°C, and its decomposition temperature exceeds 500°C, confirmed by thermogravimetric analysis (TGA).
Abrasion resistance is exceptional, withstanding at least 60,000 cycles based on the Martindale method (ISO 12947-2). Cut resistance meets EN388 Level D and ANSI A4 standards, ensuring safety and durability in demanding applications.
When exposed to heat at 250°C for 30 minutes, the fabric shows minimal shrinkage, limited to 1.5% or less. The standard color is a natural golden yellow, though dyed options are available upon request. The minimum order quantity is generally 500 meters, but this is negotiable depending on customer needs.
Applications:
Industry Applications
In the field of
Personal Protective Equipment (PPE)
, materials are used to manufacture firefighter turnout gear outer shells, welding aprons, foundry suits, cut-resistant gloves and sleeves, as well as anti-slash clothing. These applications prioritize durability and protection for users working in hazardous environments.
The
Ballistic & Armor
industry utilizes specialized fabrics for bulletproof vest backing layers, spall liners, helmet shells, and vehicle armor spall guards. These components are critical in providing safety and defense against ballistic threats.
Within
Industrial Filtration
, high-temperature dust filter bags and hot gas filtration media are employed, especially in facilities such as cement plants, steel mills, and incineration plants. These materials withstand extreme conditions while ensuring efficient filtration.
The
Automotive & Aerospace
sectors benefit from these materials in various forms including brake pad reinforcement, clutch facings, gaskets, thermal insulation blankets, and composite structural layers. These applications enhance performance, safety, and heat resistance.
In applications related to
Friction & Sealing
, industrial gaskets, expansion joints, compensators, and high-temperature conveyor belts are manufactured using these advanced fabrics. The focus lies on durability and maintaining integrity under mechanical stress.
For
Composite Reinforcement
, these materials serve as prepreg base fabrics for carbon-aramid hybrid composites, honeycomb core face sheets, and are also used in sporting goods such as skis, surfboards, and racing hulls. This enhances strength and reduces weight in high-performance products.
Lastly, in the area of
Electrical Insulation
, the fabrics are applied for transformer coil wrapping, motor slot liners, and high-temperature cable wraps. These applications require excellent electrical insulating properties combined with thermal resistance.
Customization:
Our Para Aramid Fabric product, model number Tdzpaw260, is a high-quality aramid fabric designed to meet rigorous standards with EN 11612 certification. Originating from China, this para aramid fabric offers excellent anti cut performance at Level 3, making it ideal for protective applications.
We provide product customization services to suit your specific needs. The fabric is available in rolls of approximately 100 meters each, with a standard roll length of 100m which can also be customized upon request. The thickness of the fabric is 0.3mm, and it features a 2/1 twill style in a raw yellow color.
The minimum order quantity for our para aramid fabric is 1000 meters, priced at 12 dollars per meter. Packaging is done carefully with about 100 meters per roll to ensure safe delivery. We maintain a supply ability of 3000 meters per day and offer a delivery time of 30 days after order confirmation.
Payment terms are flexible with T/T accepted. Whether you require standard or customized roll lengths, our anti cut fabric is tailored to meet your specifications while maintaining superior quality and durability.
Support and Services:
Our Para Aramid Fabric is designed to deliver exceptional strength, durability, and resistance for a wide range of applications including protective clothing, composites, and industrial materials. To ensure optimal performance and longevity of the fabric, please follow the recommended handling and care guidelines.
When cutting or sewing the Para Aramid Fabric, use sharp tools and appropriate needles to prevent fraying and damage to the fibers. It is advisable to use stainless steel or titanium-coated needles for best results.
For cleaning, avoid using bleach or strong alkaline detergents as they can degrade the fabric’s performance properties. Instead, use mild detergents and cold water. Air drying is recommended to maintain the integrity of the fibers.
Store the fabric in a cool, dry place away from direct sunlight and sources of heat to prevent any deterioration. Keep the fabric rolled or flat to avoid creasing or distortion.
If you encounter any issues with the product or require technical assistance, please refer to the product datasheets and handling manuals provided. Our technical support team is available to assist with any inquiries related to product specifications, application techniques, or troubleshooting.
For custom orders or specialized applications, we offer consultation services to help you select the right type and grade of Para Aramid Fabric to meet your specific requirements.
We are committed to providing high-quality products and support to ensure your complete satisfaction with our Para Aramid Fabric. Please adhere to the provided guidelines to maximize the performance and lifespan of the fabric in your applications.
Packing and Shipping:
Our Para Aramid Fabric is carefully packaged to ensure maximum protection during transit. Each roll is tightly wound and wrapped with a protective plastic film to prevent moisture, dust, and damage. The wrapped rolls are then placed in sturdy cardboard tubes or boxes, depending on the order size and customer requirements.
For shipping, we use durable outer cartons reinforced with padding materials to safeguard the fabric from impacts and compression. All packages are clearly labeled with product information, handling instructions, and shipping details to facilitate smooth logistics.
We offer flexible shipping options including air, sea, and land freight, tailored to meet delivery timelines and budget considerations. Our logistics partners ensure timely and secure delivery to your specified destination worldwide.
FAQ:
Q1: What is the brand and model number of this Para Aramid Fabric?
A1: The brand name is Para Aramid and the model number is Tdzpaw260.
Q2: Where is the Para Aramid Fabric manufactured?
A2: This fabric is made in China.
Q3: What certifications does the Para Aramid Fabric have?
A3: The fabric is certified with EN 11612, which ensures protection against heat and flames.
Q4: What is the minimum order quantity and price per meter?
A4: The minimum order quantity is 1000 meters, and the price is 12 dollars per meter.
Q5: How is the Para Aramid Fabric packaged and what is the delivery time?
A5: The fabric is packaged in rolls of about 100 meters each, and the delivery time is approximately 30 days.
Q6: What are the payment terms and supply ability for this product?
A6: Payment is accepted via T/T, and the supply ability is 3000 meters per day.
