Product Description:
The material possesses inherent flame resistance, with a Limiting Oxygen Index (LOI) of 28% or higher. It self-extinguishes immediately once the flame source is removed, exhibiting no melting, dripping, or afterglow. This performance surpasses the requirements set by NFPA 701 and ASTM D6413 standards, ensuring permanent thermal protection that remains effective without washing out or deteriorating over time.
It also features exceptional tensile strength, measuring at least 3.2 GPa, which is approximately five times stronger than steel wire when compared on an equal-weight basis. This remarkable strength allows it to endure extreme mechanical stresses in demanding applications such as ballistic panels, conveyor belts, and structural reinforcements.
Designed for heavy-duty usage, the fabric demonstrates superior abrasion resistance, capable of withstanding no less than 60,000 Martindale cycles. This endurance results in a service life three to five times longer than that of conventional polyester or nylon fabrics, making it ideal for friction-heavy environments like industrial sleeves, gaskets, and protective covers.
The material offers high cut resistance, rated at EN388 Level D and equivalent to ANSI levels A4–A5. Thanks to its tightly woven structure, it effectively resists slashing and cutting forces. This makes it a perfect choice for protective gloves, sleeves, aprons, and shielding equipment used in industries such as metal fabrication, glass handling, and automotive manufacturing.
Its excellent thermal stability allows it to operate continuously at temperatures up to 250°C, with a decomposition temperature exceeding 500°C. This ensures that the material maintains its mechanical integrity even under extreme heat conditions, showing no shrinkage or degradation.
Additionally, the fabric exhibits good chemical resistance, performing reliably against most organic solvents, oils, and acids, with the exception of concentrated sulfuric and nitric acids. This makes it suitable for use in harsh chemical processing and filtration environments.
Despite its robust properties, the material remains lightweight at 260 grams per square meter. This optimal balance between strength and weight allows it to be thin enough for use in multi-layer composite laminations while still being strong enough to function effectively as a standalone material.
Features:
Para-aramid woven fabric with a weight of 260 gsm is widely regarded as the benchmark in high-performance industrial textiles. Crafted entirely from 100% para-aramid fibers, equivalent in quality to Kevlar®, this fabric offers a unique blend of intrinsic flame resistance, exceptional tensile strength, and outstanding abrasion durability, all within a lightweight material.
In contrast to flame-retardant fabrics that rely on surface treatments which diminish after multiple washes, the fire resistance of para-aramid is inherent at the molecular level, being integrated into the polymer chains themselves. When exposed to extreme heat, the fabric will char but it does not melt, drip, or fuel combustion. This ensures consistent and dependable protection over the entire lifespan of the product.
Weighing in at 260 grams per square meter, this fabric achieves the perfect balance for demanding applications. It is substantial enough to provide robust protection, while remaining lightweight and flexible, making it ideal for comfortable wearable gear and adaptable composite layering. Additionally, its plain or twill weave structure imparts even strength in both the warp and weft directions, reducing the directional weaknesses commonly found in unidirectional fabrics.
Technical Parameters:
Technical Specifications
This product is crafted from 100% para-aramid fiber, ensuring excellent strength and durability. The fabric’s weight is approximately 260 grams per square meter, with a tolerance of plus or minus 10 grams, as measured by the ISO 3801 standard.
The weave type is customizable, offering options between plain and twill patterns to suit various requirements. Thickness ranges from about 0.35 to 0.40 millimeters, adhering to the ISO 5084 testing method. Width is flexible as well, with customizable dimensions between 100 and 160 centimeters.
In terms of mechanical properties, the fabric demonstrates remarkable tensile strength. The warp direction has a minimum tensile strength of 2,500 Newtons per 5 centimeters, while the weft direction is rated at 2,200 Newtons per 5 centimeters, both evaluated under ISO 13934-1 standards. Tear strength is also robust, with the warp and weft directions measuring at least 150 Newtons and 130 Newtons respectively, tested according to ISO 13937-2.
Safety and durability are enhanced by a Limiting Oxygen Index (LOI) of at least 28%, per ASTM D2863, which indicates good flame resistance. The continuous operating temperature range stretches from -50°C up to +250°C, and the fabric can withstand decomposition temperatures exceeding 500°C as determined by Thermogravimetric Analysis (TGA).
In addition, this material offers outstanding abrasion resistance, enduring a minimum of 60,000 cycles in the Martindale test (ISO 12947-2). Its cut resistance meets stringent standards, classified as EN388 Level D and ANSI A4 according to EN388:2016 and ANSI 105 standards respectively. Heat shrinkage after exposure to 250°C for 30 minutes remains low, at or below 1.5%.
The fabric naturally exhibits a golden yellow color, though dyed options are available to meet different aesthetic requirements. The minimum order quantity is 500 meters, but this can be negotiated based on specific needs.
Applications:
The Personal Protective Equipment (PPE) sector utilizes specialized materials for various safety products. These include firefighter turnout gear outer shells, welding aprons, foundry suits, cut-resistant gloves and sleeves, as well as anti-slash clothing designed to protect workers from various hazards.
In the Ballistic and Armor industry, the materials are employed as backing layers for bulletproof vests, spall liners, helmet shells, and vehicle armor spall guards, all contributing to enhanced protection against ballistic threats.
The Industrial Filtration field makes use of high-temperature dust filter bags and hot gas filtration media. These materials are critical in demanding environments such as cement plants, steel manufacturing, and incineration facilities, where they serve to efficiently filter particulates under extreme conditions.
The Automotive and Aerospace industries incorporate these materials for various applications including brake pad reinforcement, clutch facings, gaskets, thermal insulation blankets, and composite structural layers, which contribute to the safety, durability, and efficiency of vehicles and aircraft.
Friction and Sealing products benefit from industrial gaskets, expansion joints, compensators, and high-temperature conveyor belts. These components are essential for maintaining seals and reducing wear in high-stress industrial environments.
In the realm of Composite Reinforcement, the materials serve as prepreg base fabrics for carbon-aramid hybrid composites. They are also used for honeycomb core face sheets and in the manufacture of sporting goods such as skis, surfboards, and racing hulls, enhancing strength and performance.
Lastly, Electrical Insulation applications include transformer coil wrapping, motor slot liners, and high-temperature cable wraps. These materials provide crucial insulation to electrical components, ensuring reliability and safety under demanding thermal conditions.
Customization:
Our Para Aramid Fabric, model number Tdzpaw260, is a premium fire proof fabric designed to meet rigorous safety standards. Originating from China and certified with EN 11612, this para aramid fabric offers exceptional durability and protection. With a minimum order quantity of 1000 meters and a competitive price of 12 dollars per meter, it is ideal for large-scale industrial applications.
The fabric is packaged in convenient rolls of about 100 meters each, wrapped securely in nylon bags to ensure safe delivery. We maintain a supply ability of 3000 meters per day, with an estimated delivery time of 30 days. Payment is accepted via T/T to provide a smooth transaction process.
This anti cut fabric features a width of 150cm and a water washing dimensional change rate of just 3%, ensuring stability and reliability in various environments. The fabric has a pH value between 5-7 and light fastness rated as bad, which should be considered depending on application. Choose our Para Aramid fire proof fabric for effective protection and superior quality in your textile needs.
Support and Services:
Our Para Aramid Fabric is engineered to provide exceptional strength, durability, and resistance for a wide range of industrial and protective applications. To ensure optimal performance and longevity of the fabric, please follow the recommended handling, storage, and maintenance guidelines.
Handling: Always handle the fabric with clean hands or gloves to prevent contamination. Avoid sharp objects and abrasive surfaces that could damage the fibers. When cutting, use sharp tools to maintain clean edges and prevent fraying.
Storage: Store the Para Aramid Fabric in a cool, dry place away from direct sunlight and sources of heat. Keep the fabric rolled or flat to avoid creasing or deformation. Ensure the storage area is free from chemicals and moisture that may degrade the material.
Cleaning: Clean the fabric using mild detergents and cold water. Avoid bleach, chlorine, and harsh chemicals that can weaken the fibers. Air dry the fabric away from direct heat or sunlight to maintain its structural integrity.
Inspection and Maintenance: Regularly inspect the fabric for signs of wear, damage, or contamination. Replace or repair any sections that show significant degradation to maintain safety and performance standards.
Technical Support: For assistance with product selection, application guidelines, or troubleshooting, our technical support team is available to provide expert advice and solutions tailored to your specific needs.
Warranty and Service: The Para Aramid Fabric comes with a warranty against manufacturing defects. Please refer to the warranty documentation for detailed terms and conditions. For service inquiries, please consult the product support resources provided with your purchase.
Packing and Shipping:
Our Para Aramid Fabric is carefully packaged to ensure maximum protection during transit. Each roll is tightly wound and wrapped with a protective plastic film to prevent moisture and dust contamination. The wrapped fabric is then placed in sturdy, reinforced cardboard tubes or boxes, providing structural integrity and safeguarding against physical damage.
For shipping, we use reliable freight services that handle products with care. The packages are clearly labeled with handling instructions and product details to facilitate smooth customs clearance and delivery. Depending on the order size, shipments are consolidated on pallets, securely strapped, and covered with stretch film to prevent shifting during transport.
We also offer customized packaging solutions on request to meet specific customer requirements. Our goal is to ensure that the Para Aramid Fabric arrives at your facility in perfect condition, ready for immediate use.
FAQ:
Q1: What is the brand and model number of this Para Aramid Fabric?
A1: The brand name is Para Aramid, and the model number is Tdzpaw260.
Q2: Where is the Para Aramid Fabric manufactured?
A2: This Para Aramid Fabric is made in China.
Q3: What certification does the Para Aramid Fabric have?
A3: It is certified with EN 11612, ensuring it meets specific protective clothing standards.
Q4: What is the minimum order quantity and price per meter?
A4: The minimum order quantity is 1000 meters, priced at 12 dollars per meter.
Q5: How is the Para Aramid Fabric packaged and what is the delivery time?
A5: The fabric is packaged in rolls of about 100 meters each, with a delivery time of approximately 30 days.
Q6: What are the payment terms and daily supply capacity?
A6: Payment terms are T/T (Telegraphic Transfer), and the supply ability is 3000 meters per day.
