Product Details:
|
| Name: | Aramid FR Viscose Blended Fabric | Tear Strength: | 94/80N |
|---|---|---|---|
| Color Fastness: | Level 5 | After Glow Time: | 0.8s |
| Application: | Protect Clothe | Breakstrength: | 900N/1200N |
| After Flame Time: | 0 S | Compsition: | 93%meta Aramid ,5% Para Aramid ,2%antistatic |
| Highlight: | flame resistance meta aramid fabric,uv resistance meta aramid fabric,heat resistant industrial clothing fabric |
||
Aramid fabric is known for its exceptional flame-retardant properties. It does not melt or drip when exposed to fire, ensuring safety during high-temperature conditions. The fabric burns without releasing toxic substances, making it a safer choice for various protective applications. Additionally, it boasts excellent chemical resistance, enhancing its durability in harsh environments. This makes aramid fabric ideal for use in flame-retardant sofas, fire-retardant curtains, and other related fields.
Our aramid fabrics utilize both domestic and imported meta-aramid fibers, combined with para-aramid and conductive fibers to improve performance. These fabrics comply with a range of rigorous standards, including EN532, EN11612, EN14116, GA2002-10, GB8965-1998, and GB12014-89, ensuring reliable quality and safety.
The fabric weights range from 120 grams per square meter (g/m²) to 300 g/m², with the most commonly used weights being 150 g/m², 180 g/m², 220 g/m², and 260 g/m². This variety allows customization based on specific application requirements.
Available in a wide selection of colors, the fabric includes navy blue, royal blue, black, green, dark green, light blue, red, orange, yellow, and khaki. This versatility in color options makes it suitable for different design needs.
Due to its outstanding protective qualities, aramid fabric finds wide applications in manufacturing fire suits, uniforms for military personnel, and equipment for the aviation sector. It is also extensively used in the petrochemical industry and electric power industry, where flame resistance and durability are critical.![]()
The following specifications detail the composition, weave structure, yarn details, weight, and width of various aramid fabrics and aramid blended fabrics.
The aramid fabrics are primarily composed of meta-aramid and para-aramid fibers, sometimes combined with antistatic materials. They are woven in plain or twill weaves with different yarn counts and weights.
| Item | Ingredients | Weave Structure | Yarn Count | Weight (g/m²) | Weight (oz/yd²) | Width (inches) |
|---|---|---|---|---|---|---|
| Aramid fabric | 93% meta aramid, 5% para aramid, 2% antistatic | 1/1 plain | 40s/2 | 150 | 4.5 | 58/60 |
| Aramid fabric | 98% meta aramid, 2% antistatic | 2/1 twill | 32s/2 | 220 | 6.5 | 58/60 |
| Aramid fabric | 93% meta aramid, 5% para aramid, 2% antistatic | 2/1 twill | 35s/2 | 210 | 6.2 | 58/60 |
| Aramid fabric | 60%meta aramid , 40% FR viscose | 2/1 twill | 35s/2 | 260 | 7.7 | 58/60 |
These fabrics blend meta-aramid fibers with flame retardant viscose (FR viscose) to achieve a balance of performance and comfort. The weave structures are predominantly plain or twill, with varying yarn specifications and fabric weights.
| Item | Ingredients | Weave Structure | Yarn Count | Weight (g/m²) | Weight (oz/yd²) | Width (inches) |
|---|---|---|---|---|---|---|
| Aramid Adhesive | 50% meta aramid, 50% FR viscose | 1/1 plain | 28s/1 | 120 | 3.5 | 63 |
| Aramid Adhesive | 50% meta aramid, 50% FR viscose | 1/1 plain | 26s/1 | 130 | 3.8 | 63 |
| Aramid Adhesive | 35% meta aramid, 65% FR viscose | 1/1 plain | 35s/2 | 170 | 5.0 | 63 |
| Aramid Adhesive | 65% meta aramid, 35% FR viscose | 2/1 twill | 40s/2 | 180 | 5.3 | 58/60 |
| Aramid Adhesive | 65% meta aramid, 35% FR viscose | 2/1 twill | 38s/2 | 205 | 6.0 | 58/60 |
| Aramid Adhesive | 50% meta aramid, 50% FR viscose | 2/1 twill | 28s/2 | 255 | 7.5 | 58/60 |
Our Meta Aramid Fabric, branded as aramid fabric with model number TDZ200 FRMA, is a high-quality, heat resistant material originating from China. Certified to EN 11612 standards, this aramid babric is designed to provide superior protection for protective clothing applications.
The fabric composition consists of 93% meta Aramid, 5% Para Aramid, and 2% antistatic fibers, ensuring excellent durability and safety. It boasts a color fastness level of 5, a break strength of 900N/1200N, and a damaged length of only 4.5 cm, making it reliable for demanding environments.
We offer a minimum order quantity of 1000 meters, priced at 11 dollars per meter, with packaging details of approximately 90 meters per roll. Our supply ability is 3000 meters per day, with a delivery time of 60 days. Payment terms are T/T.
Choose our meta araimid fabric for your protective clothing needs, benefiting from its heat resistant properties and robust performance as a premium aramid babric.
Meta Aramid Fabric is designed to provide exceptional heat resistance and durability for a variety of industrial applications. To ensure optimal performance and longevity of the fabric, please follow the recommended care and handling guidelines.
When handling Meta Aramid Fabric, avoid exposure to strong acids, alkalis, and excessive moisture. Store the fabric in a cool, dry place away from direct sunlight and UV exposure to maintain its structural integrity.
For cleaning, use a mild detergent and lukewarm water. Avoid using bleach, fabric softeners, or harsh chemicals that can degrade the fibers. Gently hand wash or use a delicate cycle in a washing machine, then air dry the fabric away from direct heat sources.
If the fabric is used in applications involving high abrasion or mechanical stress, regularly inspect it for signs of wear or damage. Replace any sections that show significant deterioration to maintain safety and effectiveness.
For technical support, product specifications, or assistance with custom applications, please refer to the product documentation or visit our official website for detailed resources and FAQs.
The Meta Aramid Fabric is carefully packaged to ensure maximum protection during transit. Each roll of fabric is tightly wound and wrapped with a protective plastic layer to prevent moisture and dust contamination. The wrapped fabric is then placed inside a sturdy cardboard tube or box, depending on the order size, to avoid any damage or deformation.
For shipping, we use reliable carriers that provide tracking and insurance options to guarantee safe delivery. Packages are labeled clearly with handling instructions such as "Fragile" and "Keep Dry" to ensure proper care throughout the shipping process. We also offer customized packaging solutions upon request to meet specific customer requirements.
Our commitment to quality packaging and secure shipping ensures that the Meta Aramid Fabric arrives in excellent condition, ready for immediate use in your applications.
Q1: What is the brand and model number of this Meta Aramid Fabric?
A1: The brand name is aramid fabric and the model number is TDZ200 FRMA.
Q2: Where is the Meta Aramid Fabric manufactured?
A2: This product is made in China.
Q3: What certification does the Meta Aramid Fabric have?
A3: The fabric is certified with EN 11612, ensuring its flame-resistant properties.
Q4: What is the minimum order quantity and price per meter?
A4: The minimum order quantity is 1000 meters, priced at 11 dollars per meter.
Q5: How is the fabric packaged and what is the delivery time?
A5: The fabric is packed in rolls of about 90 meters each, with a delivery time of approximately 60 days.
Q6: What payment terms and supply ability do you offer?
A6: Payment is accepted via T/T, and we can supply up to 3000 meters per day.
